Description
JSW Color Coated Wall Liners are aesthetically finished and structurally strong pre-painted galvanized or Galvalume® steel sheets, tailored for vertical wall cladding, ceilings, and partitioning in modern buildings. Designed to complement JSW’s roofing and structural systems, these wall liners offer durability, easy maintenance, and design flexibility.
Backed by JSW Steel’s quality standards, these panels are roll-formed into attractive profiles and available in various colours, thicknesses, and coatings to suit diverse architectural requirements.
Technical Specifications:
Specification Typical Value / Options
Base Metal Galvalume® / Galvanized Steel
Coating AZ150 / Z120 with RMP, SMP, or PVDF Paint
Sheet Thickness 0.40MM
Width (Effective) 1105MM
Length Custom lengths available (up to 6m+)
Surface Finish Glossy / Matt / Textured
Application Orientation Vertical or Horizontal Wall Cladding
Applications:
Factory interiors & exterior wall cladding
Warehouses and industrial buildings
Commercial complex façades
Pre-engineered building (PEB) wall systems
Partition panels and false ceiling liners
Residential utility spaces (e.g. garages, basements)
